🔍 Real-Time Energy Monitoring with LoRaWAN®

Milesight CT305 is a compact and powerful LoRaWAN® current transformer sensor designed to measure and transmit real-time AC current data. Supporting both RMS current and calculated power, it enables effortless remote monitoring of equipment, machinery, or building-level power consumption without intrusive wiring.

📌 Key Features

  • 🔁 Dual Current Transformer Inputs – Simultaneously monitor two independent AC lines (up to 200 A per channel)

  • 📊 High-Precision RMS Current Measurement

  • 🔋 Up to 10 Years Battery Life – Powered by replaceable 19000 mAh Li-SOCL₂ battery

  • 🧲 Non-Invasive Installation – Easy clip-on CT sensors, no wire cutting

  • 📡 LoRaWAN® Connectivity – Long-range wireless transmission (EU868 band)

  • 📁 Supports Delta or Wye Configurations

  • 🔧 Compatible with Milesight Toolbox App for configuration via NFC

  • 🌡️ Operating Temperature: -30°C to +60°C

  • 🏢 Ideal for energy audits, predictive maintenance, and industrial asset monitoring

📦 Package Includes

  • CT305 Sensor Unit

  • 2 x Split-core CT clamps (rated current selected at order)

  • Mounting accessories

  • Quick Start Guide

📚 Product Downloads

🎥 Product Video



• Model: Milesight CT305 • Wireless Technology: LoRaWAN® • LoRaWAN® Frequency: EU868 • Current Channels: 2 • Rated Current: Up to 200 A (per channel) • Power Calculation: Apparent Power (VA) • Measurement: RMS Current • Sampling Rate: 1 sample per second (internal), 1 report per TDC • CT Sensor Type: Split-core, clip-on • Accuracy: ±1% (typical) • Power Supply: 19000 mAh Li-SOCL₂ Battery (replaceable) • Battery Life: Up to 10 years • Configuration: NFC via Milesight Toolbox • Operating Temperature: -30°C to +60°C • Protection Rating: IP30 • Mounting: Wall or DIN rail • Dimensions: 115 × 70 × 30 mm • Certifications: CE, RoHS
