Included external probe: E31F measures both temperature and relative humidity, with a 2m cable. It is not a temperature-only E3 probe. User notifications can be configured in the connected IoT platform.
-
The Dragino LHT65N-E31F is a professional LoRaWAN® Temperature & Humidity Sensor (EU868) designed for long-range environmental monitoring, cold chain applications, warehouses, greenhouses and industrial IoT installations.
The device combines built-in temperature and humidity sensing with an included E31F external temperature and humidity probe on a 2m cable.
Using LoRaWAN Class A technology, the LHT65N-E31F transmits environmental measurements over long distances while maintaining low power consumption. It can be integrated with compatible LoRaWAN gateways, network servers and IoT monitoring platforms.
Its battery-powered design supports long-term operation without external power wiring, making it suitable for distributed monitoring installations.
Temperature and humidity notifications can be configured through the connected IoT monitoring platform, according to its functions.
The LHT65N-E31F is a practical solution for applications requiring reliable wireless monitoring of ambient conditions and external temperature measurement.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
💡 Key Features
🌡️ Temperature Monitoring – Internal temperature measurement for environmental monitoring.
💧 Humidity Monitoring – Integrated relative humidity sensor.
🔌 External Temperature & Humidity Probe Included – External temperature and humidity measurement using the included E31F probe.
📡 LoRaWAN EU868 – Long-range wireless communication with low power consumption.
🔋 Battery-Powered Operation – Designed for long-term monitoring without external power wiring.
🚨 Temperature & Humidity Alerts – Threshold notifications through a compatible IoT platform.
📊 Data Logging – Support for historical measurement records and data retrieval.
🏢 Flexible Installation – Suitable for warehouses, technical rooms, greenhouses and commercial facilities.
🔗 IoT Platform Integration – Compatible with standard LoRaWAN gateways and network servers.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🛠 Applications
📦 Cold Chain Monitoring – Temperature monitoring in refrigerated storage and logistics environments.
🏭 Industrial Facilities – Monitoring ambient conditions and external temperature points.
🏢 Smart Buildings – Temperature and humidity monitoring in commercial properties.
🌱 Greenhouses – Environmental monitoring for agricultural installations.
💻 Server Rooms – Monitoring temperature and humidity around sensitive equipment.
❄️ Refrigeration Monitoring – External temperature sensing in suitable refrigeration applications.
📡 Remote IoT Monitoring – Distributed wireless environmental monitoring.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
📦 Package Information
-
1 × Dragino LHT65N-E31F LoRaWAN Temperature & Humidity Sensor (EU868)
-
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
📥 Product Downloads
- Manufacturer: Dragino
- Model: LHT65N-E31F-EU868
- Device Type: LoRaWAN Temperature & Humidity Sensor with External Probe
- Wireless Protocol: LoRaWAN 1.0.3 Class A
- Frequency Band: EU868
- Built-in Sensors: Temperature & Relative Humidity
- External Probe: Sensirion SHT31F Temperature & Humidity Sensor
- External Probe Cable Length: 2 m
- Built-in Temperature Range: -40°C to +80°C
- Built-in Temperature Resolution: 0.01°C
- Built-in Temperature Accuracy: Typically ±0.3°C
- Built-in Humidity Range: 0–96% RH
- Built-in Humidity Resolution: 0.04% RH
- Built-in Humidity Accuracy: Typically ±3% RH
- External Temperature Range: -40°C to +125°C
- External Temperature Resolution: 0.01°C
- External Temperature Accuracy: Typically ±0.3°C
- External Humidity Range: 0–96% RH
- External Humidity Resolution: 0.04% RH
- External Humidity Accuracy: Typically ±3% RH
- Battery: 2,400 mAh, Non-Rechargeable
- Estimated Battery Life: Up to 10 Years, Depending on Usage
- Data Logging: Supported During Network Outages
- Configuration: AT Commands & LoRaWAN Downlink
- Firmware Updates: Via Programming Port
- Status Indicator: Tri-Color LED
- Device Dimensions: 95 × 40 × 28 mm
- Device Weight: 105 g
