The Milesight UC511 Series is a LoRaWAN®-enabled solenoid valve controller designed for precise and efficient remote valve control in agriculture, irrigation, industrial automation, and smart water management applications.
With its integrated internal LoRaWAN® antenna (no external antenna required), the UC511 ensures a compact, durable, and highly reliable solution for remote valve operation in both indoor and outdoor environments. This controller enables long-range, low-power data transmission, event-driven control, and seamless integration with cloud-based IoT platforms.
🔑 Key Features
✔ LoRaWAN® Wireless Control – Provides long-range, low-power communication for real-time valve actuation.
✔ Integrated Internal Antenna – Eliminates the need for an external antenna while maintaining stable LoRaWAN® connectivity.
✔ Multiple Control Modes – Supports scheduled, remote, and event-triggered valve operations.
✔ Ultra-Low Power Consumption – Battery-powered design ensures years of operation without frequent maintenance.
✔ Robust & Waterproof Design – IP67-rated housing protects against dust and water, making it ideal for outdoor and harsh environments.
✔ Flexible Power Supply Options – Operates on a long-lasting battery or external DC power for uninterrupted performance.
✔ Seamless Integration with IoT Platforms – Works with Milesight IoT Cloud and third-party LoRaWAN® servers.
✔ Easy Deployment & Configuration – Supports remote firmware updates and parameter adjustments via LoRaWAN®.
📦 Technical Specifications
✅ LoRaWAN® Protocol: 1.0.3, Class C
✅ LoRa® Frequency Band: EU868
✅ LoRa® TX Power: Up to 21 dBm
✅ LoRa® Sensitivity: -137 dBm
✅ Antenna: Internal LoRaWAN® antenna (no external antenna required)
✅ Solenoid Valve Control: Supports DC latching solenoid valves (9~24V DC)
✅ Control Modes:
• Manual On/Off
• Scheduled Activation
• Remote Control via LoRaWAN®
• Event-Based Triggers
✅ Power Supply:
• Built-in high-capacity battery (replaceable)
• External 9~24V DC power input
✅ Battery Life: Up to 5 years (depending on usage)
✅ Operating Temperature: -40°C to 85°C
✅ Ingress Protection: IP67 Waterproof & Dustproof
✅ Installation: Wall-mounted, pole-mounted, or in-line with piping systems
🌍 Applications
🌾 Smart Agriculture & Precision Irrigation – Enables remote water management, crop irrigation scheduling, and automated valve control.
🏭 Industrial Automation – Provides wireless control of fluid management systems in factories, refineries, and process industries.
🚰 Smart Water Management – Supports automated water distribution, leak prevention, and consumption monitoring.
🌆 Smart Cities & Infrastructure – Integrates with urban irrigation, water conservation, and public utility systems.
🏠 Building Automation – Ideal for HVAC water flow control and automated facility water distribution.
📥 Product Downloads:
Product Video
- Device Type: LoRaWAN® Solenoid Valve Controller
- Valve Control: Supports control of 1 solenoid valve (DC latching type)
- Output: 9-24 VDC pulse output for valve control
- Digital Inputs: Supports dry contact input for status detection
- Antenna: Integrated internal antenna (no external antenna)
- LoRaWAN® Protocol: 1.0.3, Class A
- Frequency Band: EU868 MHz
- LoRa® TX Power: Up to 16 dBm (Adjustable)
- LoRa® Sensitivity: -137 dBm (SF12)
- Power Supply: Replaceable internal battery (up to 5 years lifespan)
- Ingress Protection: IP67 (Outdoor & harsh environments)
- Operating Temperature: -20°C to 60°C
- Installation: Wall or pole mounting
- Additional Features: Compact and wireless, ultra-low power consumption, remote control and monitoring, ideal for smart irrigation, smart agriculture, water management, landscaping, and industrial valve control applications
