Milesight WS503 – LoRaWAN Smart Wall Switch (3-Gang)
Milesight WS503 – LoRaWAN Smart Wall Switch (3-Gang)
Milesight WS503 – LoRaWAN Smart Wall Switch (3-Gang)
Milesight WS503 – LoRaWAN Smart Wall Switch (3-Gang)

Milesight WS503 – LoRaWAN Smart Wall Switch (3-Gang)

Availability: In stock

€118,00

VAT Exemption for EU Businesses: Validate Your VAT Number at Checkout

Prices do not include VAT (Your local VAT & Shipping Cost will be calculated at Checkout)

Vendor:
Milesight

Smart LoRaWAN® Wall Switch for Advanced Lighting & Building Automation

The Milesight WS503 is an intelligent LoRaWAN® smart wall switch designed for the local and remote control of lighting systems and electrical appliances in smart homes, offices, hotels and commercial buildings. As part of the Milesight WS50x Series, the WS503 provides three independent switch channels, enabling flexible control of multiple lighting circuits or electrical loads from a single wall switch.

The WS503 can directly replace traditional wall switches while adding LoRaWAN® wireless connectivity, remote management, automation capabilities and real-time energy monitoring. Users can control connected devices locally through the wall switch buttons or remotely through LoRaWAN® networks, cloud platforms and mobile applications.

In addition to switching functionality, the WS503 supports voltage, current, active power, power factor and energy consumption monitoring, helping improve energy efficiency and reduce operational costs. Built-in overload protection ensures safe operation and protects connected electrical loads.

The device also supports Milesight D2D (Device-to-Device) communication, enabling direct wireless interaction between Milesight devices without requiring a LoRaWAN® gateway. NFC configuration allows fast deployment and simple device management through the Milesight ToolBox mobile application.

With elegant design, industrial reliability and long-range wireless connectivity, the WS503 is ideal for professional smart building and energy management projects.

Key Features

✔ LoRaWAN® Smart Wall Switch
✔ 3-Gang Wall Switch Design
✔ Local & Remote ON/OFF Control
✔ Real-Time Power Consumption Monitoring
✔ Voltage, Current & Energy Measurement
✔ Built-in Overload Protection
✔ Milesight D2D Communication
✔ NFC Configuration via Smartphone
✔ LoRaWAN® Class C Operation
✔ Compatible with Milesight IoT Cloud
✔ Elegant Modern Design
✔ Ideal for Smart Buildings & Energy Management

Typical Specifications

• LoRaWAN® Class C
• 3-Gang Smart Wall Switch
• Input Voltage: 100 ~ 250 VAC
• Maximum Load: Up to 1000W per Gang
• Current Monitoring
• Voltage Monitoring
• Active Power Measurement
• Energy Consumption Measurement (kWh)
• NFC Configuration
• Milesight D2D Support
• IP20 Protection Rating

Applications

Smart Homes
Smart Offices
Hotels
Museums
Building Automation
Energy Monitoring
Lighting Automation
Commercial Buildings

Package Includes

✔ 1 × Milesight WS503 Smart Wall Switch
✔ Mounting Screws
✔ Quick Start Guide
✔ Warranty Card

━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━

Product Downloads :

📑 Datasheet

📘 User Manual

Product Video

  • Model: WS503
  • Type: LoRaWAN® Smart Wall Switch
  • Switch Type: 3-Gang
  • Input Voltage: 100 ~ 250 VAC
  • Maximum Load: 1000W per Gang
  • Maximum Current: 10A Resistive / 5A Inductive
  • Measurements: Voltage, Current, Active Power, Power Factor, Energy Consumption
  • Protocol: LoRaWAN® Class C
  • Configuration: NFC
  • Protection: IP20
  • Operating Temperature: -20°C ~ +60°C
