Dragino SCT013G-D-100 Split-Core Current Transformer (100A / 50mA)

Availability: In stock

€11,00

VAT Exemption for EU Businesses: Validate Your VAT Number at Checkout

Prices do not include VAT (Your local VAT & Shipping Cost will be calculated at Checkout)

Vendor:
Dragino

The Dragino SCT013G-D-100 is a high-precision split-core current transformer designed for accurate AC current measurement up to 100A, with a standard 50mA output.

Its non-invasive clamp design allows quick installation without disconnecting cables, making it ideal for retrofitting in existing electrical systems.

Perfectly compatible with Dragino solutions such as the CS01-LB LoRaWAN Current Sensor Converter, this CT sensor is widely used in energy monitoring, industrial automation, and smart building applications.

⚡ Key Benefits

✔️ Non-invasive installation (no cable cutting required)
✔️ High accuracy current measurement
✔️ Compact & durable design
✔️ Wide operating temperature range
✔️ Ideal for IoT & energy monitoring systems

🌍 Typical Applications

  • Energy consumption monitoring
  • Smart building & facility management
  • Industrial load monitoring
  • Solar energy systems
  • IoT-based remote energy analytics

📊 Product Features

  • 🔹 Split-core current transformer for easy installation
  • 🔹 Measurement range up to 100A AC
  • 🔹 Standard output: 50mA
  • 🔹 High accuracy (approx. ±1%)
  • 🔹 Compatible with Dragino CS01 series
  • 🔹 Durable ferrite core construction
  • 🔹 Suitable for industrial & commercial environments

📐 Technical Specifications

  • Model: SCT013G-D-100
  • Type: Split-core current transformer
  • Measuring Range: 0 – 100A AC
  • Output: 50mA
  • Accuracy: ±1% (typical)
  • Aperture Diameter: 16 mm
  • Operating Temperature: -40°C to +85°C
  • Cable Length: ~1m
  • Dimensions: ~34 × 32 × 22 mm
  • Weight: ~80g
  • Core Type: Ferrite split-core

📦 Package Includes

  • 1 × SCT013G-D-100 Current Transformer
