Eastron SDM630MCT-MOD-MID V2 Three-Phase CT Energy Meter – RS485 Modbus RTU
Availability: In stock
VAT Exemption for EU Businesses: Validate Your VAT Number at Checkout
Prices do not include VAT (Your local VAT & Shipping Cost will be calculated at Checkout)
The Eastron SDM630MCT-MOD-MID V2 is a professional three-phase, CT-operated digital electricity meter with RS485 Modbus RTU communication and MID certification, designed for accurate energy measurement, submetering and electrical monitoring in commercial, industrial and building management applications.
Unlike direct-connected electricity meters, the SDM630MCT-MOD-MID V2 measures current through external current transformers (CTs), making it suitable for electrical installations with higher current ratings and applications where CT-based measurement is required.
The meter provides comprehensive monitoring of electrical parameters, including voltage, current, active power, reactive power, apparent power, power factor, frequency and active energy consumption. It supports the analysis of electricity usage and the monitoring of electrical installations.
Equipped with an RS485 Modbus RTU interface, the SDM630MCT-MOD-MID V2 can communicate with compatible PLCs, SCADA systems, building management systems (BMS), industrial gateways and energy monitoring platforms.
The meter supports bidirectional energy measurement, enabling the monitoring of imported and exported electrical energy in suitable installations.
Its MID-certified configuration is designed for applications requiring certified active energy measurement, subject to the exact model's conformity documentation, correct installation and applicable national regulations.
The device features a backlit LCD display, providing convenient local access to measurement data, and a compact 72 mm DIN-rail enclosure, suitable for installation in electrical distribution panels.
With CT-based measurement, Modbus communication and comprehensive electrical monitoring capabilities, the Eastron SDM630MCT-MOD-MID V2 is an effective solution for energy management, commercial submetering, industrial monitoring and building automation projects.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🔑 Key Features
⚡ Three-Phase Energy Measurement – Accurate measurement of electrical energy in compatible three-phase installations.
🔌 CT-Operated Measurement – Uses external current transformers for current measurement without direct connection of the load current through the meter.
📡 RS485 Modbus RTU Communication – Integration with PLC, SCADA, BMS and energy monitoring platforms.
📊 Multifunction Electrical Monitoring – Measures voltage, current, active power, reactive power, apparent power, power factor, frequency and energy.
📜 MID-Certified Version – Designed for certified active energy metering and submetering applications.
🔄 Bidirectional Energy Measurement – Supports monitoring of imported and exported electrical energy.
⚙️ Configurable CT Ratio – Supports configuration for compatible current transformers, subject to the restrictions of the MID version.
🔔 Pulse Outputs – Provides pulse output functionality for compatible monitoring equipment.
🖥️ Backlit LCD Display – Clear local display of electrical measurements and settings.
🏗️ DIN-Rail Mounting – Compact 72 mm housing for electrical distribution panels.
🏢 Building & Industrial Integration – Suitable for commercial facilities, factories and energy management systems.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🛠 Applications
🏭 Industrial Energy Monitoring – Measurement of electricity consumption and electrical parameters in industrial installations.
🏢 Commercial Buildings – Energy monitoring and submetering across building systems.
🏬 Multi-Tenant Properties – Measurement of energy consumption in individual installations or tenant areas.
⚡ Electrical Distribution Panels – Three-phase CT-based electricity monitoring.
☀️ Solar & Renewable Energy Installations – Monitoring imported and exported energy where the electrical design and meter configuration permit.
📊 Energy Management Systems – Integration of consumption and electrical measurements into monitoring software.
🔧 BMS, PLC & SCADA Systems – Modbus RTU integration with compatible automation systems.
🌱 Energy Efficiency Projects – Analysis of energy consumption and identification of opportunities for improved efficiency.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
📦 Package Includes
-
1 × Eastron SDM630MCT-MOD-MID V2 Three-Phase CT Energy Meter
Important: External current transformers (CTs) are required for current measurement and are not assumed to be included.
The CT secondary rating and transformation ratio must match the meter configuration. Correct CT ratio programming is particularly important for the MID version, as programming restrictions may apply.
Installation must be performed by a qualified electrician according to the manufacturer's instructions and applicable electrical regulations.
📥 Product Downloads
- Manufacturer: Eastron
- Model: SDM630MCT-MOD-MID V2
- Device Type: Three-Phase CT Energy Meter
- Measurement Method: External Current Transformers (CT)
- Electrical System: Three-Phase AC
- CT Secondary Input: 1 A / 5 A (Verify Exact Version)
- CT Ratio: Configurable; MID Programming Restrictions Apply
- Communication Interface: RS485
- Communication Protocol: Modbus RTU
- Measured Parameters: Voltage, Current, Active Power, Reactive Power, Apparent Power, Power Factor, Frequency and Energy
- Energy Measurement: Active Energy (kWh)
- Energy Direction: Imported and Exported Energy
- Certification: MID Version; Verify Exact Conformity Documentation
- Pulse Outputs: Supported
- Display: Backlit LCD
- Mounting: DIN Rail
- Housing Width: 72 mm (4 DIN Modules)
- Current Transformers Included: No, Unless Specifically Supplied as a Kit
- Applications: Energy Monitoring, Submetering, BMS, Industrial Automation
