Milesight EM500-SWL LoRaWAN Submersible Water Level Sensor – Reliable & Accurate Water Level Monitoring (Measuring Range 3m) - EU868

  1. Home
  2. All Products
  3. Milesight EM500-SWL LoRaWAN Submersible Water Level Sensor – Reliable & Accurate Water Level Monitoring (Measuring Range 3m) - EU868
Milesight EM500-SWL PN:L03 LoRaWAN® Submersible Water Level Sensor
Milesight EM500-SWL PN:L03 LoRaWAN Submersible Water Level Sensor (Measuring Range 3m)
Milesight EM500-SWL PN:L03 LoRaWAN Submersible Water Level Sensor (Measuring Range 3m)
Milesight EM500-SWL PN:L03 LoRaWAN Submersible Water Level Sensor (Measuring Range 3m)

Milesight EM500-SWL LoRaWAN Submersible Water Level Sensor – Reliable & Accurate Water Level Monitoring (Measuring Range 3m) - EU868

Availability: Out of stock

Available upon request, please contact us

€320,00

VAT Exemption for EU Businesses: Validate Your VAT Number at Cart Page

Prices do not include VAT (Your local VAT & Shipping Cost will be calculated at Checkout)

Vendor:
Milesight

The Milesight EM500-SWL is a high-precision LoRaWAN® submersible water level sensor, designed for real-time monitoring of water levels in wells, rivers, reservoirs, tanks, and other submerged environments. Utilizing LoRaWAN® technology, it ensures long-range, low-power wireless communication, making it an ideal solution for flood monitoring, groundwater management, and industrial water control. With an IP67-rated, corrosion-resistant stainless steel body, the EM500-SWL provides accurate measurements and long-lasting performance in harsh environments.

🔑 Key Features

✔ Real-Time Submersible Water Level Monitoring – Accurately measures liquid levels in wells, rivers, tanks, and reservoirs.
✔ LoRaWAN® Wireless Transmission – Enables long-range, low-power data transmission for remote monitoring.
✔ Multiple Pressure Range Options – Supports 05m, 010m, and 0~20m water depth measurement models for various applications.
✔ IP67 Waterproof & Corrosion-Resistant – Stainless steel housing ensures durability in submerged and harsh conditions.
✔ Long Battery Life – Equipped with a 19000mAh Li-SOCL2 battery, offering up to 10 years of maintenance-free operation.
✔ Temperature Compensation – Built-in temperature sensor for accurate readings in changing environmental conditions.
✔ Smart Alerts & Data Logging – Sends instant notifications when water levels exceed predefined thresholds.
✔ Easy Installation & Deployment – Comes with a durable cable for easy submersion into water sources.

📦 Technical Specifications

✅ Measurement Type: Submersible Water Level Sensor
✅ Measuring Range: 0~3m
✅ Accuracy: ±0.5% FS (Full Scale)
✅ Resolution: 1 mm
✅ LoRaWAN® Protocol: 1.0.3, Class A
✅ LoRa® Frequency Band: EU868
✅ LoRa® TX Power: Up to 20 dBm
✅ LoRa® Sensitivity: -137 dBm
✅ Power Supply: Built-in 19000mAh Li-SOCL2 battery (up to 10 years lifespan)
✅ Operating Temperature: -30°C to 70°C
✅ Ingress Protection: IP67 Waterproof (sensor), IP68 (probe)
✅ Installation: Submersible with cable connection

🌍 Applications

💦 Groundwater & Well Level Monitoring
🌊 River & Reservoir Water Level Tracking
🏭 Industrial Water Management & Storage Tanks
🚰 Flood Monitoring & Prevention
🌾 Irrigation Systems & Agriculture

📥 Product Downloads:

📑 Datasheet | 📘 User Manual

Product Video

  • Device Type: LoRaWAN® Submersible Water Level Sensor
  • Measurement Parameter: Water Level (Pressure-based)
  • Measuring Range: 0 to 3 meters H₂O
  • Measurement Accuracy: ±0.5% FS (Full Scale)
  • Resolution: 1 mm
  • Sensor Type: Submersible Pressure Sensor (IP68)
  • Cable Length: 3 meters (standard)
  • LoRaWAN® Protocol: 1.0.3, Class A
  • Frequency Band: EU868 MHz
  • LoRa® TX Power: Up to 16 dBm (Adjustable)
  • LoRa® Sensitivity: -137 dBm (SF12)
  • Power Supply: Replaceable 19000 mAh Li-SOCl₂ battery (up to 10 years lifespan)
  • Ingress Protection: IP67 (Sensor IP68 - Submersible)
  • Operating Temperature: -30°C to 70°C
  • Installation: Submersible sensor with wall/pole-mounted transmitter
  • Additional Features: Reliable and accurate water level measurement, ultra-low power consumption, robust industrial-grade design, ideal for shallow water tanks, wells, agriculture, environmental monitoring, and flood detection
