Dragino WSS-23 – RS485 Air Quality Sensor (CO₂, PM2.5, PM10)

Availability: In stock

€126,00

VAT Exemption for EU Businesses: Validate Your VAT Number at Cart Page

Prices do not include VAT (Your local VAT & Shipping Cost will be calculated at Checkout)

Vendor:
Dragino

Smart Air Quality Monitoring for Weather Stations

The Dragino WSS-23 is a professional air quality sensor designed to monitor CO₂, PM2.5 and PM10 simultaneously — perfect for integrating into weather station systems and environmental monitoring solutions. It uses RS485 (Modbus RTU) communication and advanced measurement technologies to deliver accurate and reliable data outdoors.



🔍 Key Features

✔ Multi-Parameter Air Quality – Measures CO₂, PM2.5 & PM10 in one device.
✔ RS485 Interface – Stable Modbus RTU data connection for industrial systems.
✔ Advanced Measurement Tech –
 • NDIR CO₂ sensor with internal temperature compensation.
 • Laser scattering for fine particle (PM2.5 & PM10) detection.
✔ Outdoor-Ready Design – Weatherproof housing for harsh environments.
✔ High Accuracy & Resolution – Accurate readings across wide ranges.

📊 Typical Specifications

• CO₂ Range: 0–5000 ppm, ±3 % FS, resolution 1 ppm.
• PM2.5/PM10 Range: 0–1000 µg/m³, ±3 % FS, resolution 1 µg/m³.
• Power: DC 7–24 V.
• Interface: RS485 (Modbus RTU).
• Operating Temp: CO₂: 0–50 °C, PM2.5/PM10: –30–50 °C.
• Humidity Operating: 0–95 % RH (CO₂); 15–80 % RH (PM2.5/PM10).
• Power Consumption: ~50 mA @ 12 V.
• Outdoor Enclosure: UV resistant, weather-proof.

📈 Applications

🌿 Smart Agriculture & Greenhouses
🌎 Outdoor Weather & Environmental Monitoring
🏙 Smart City Air Quality Networks
🏭 Industrial Pollution Control
📡 IoT & Data Logging Platforms

📦 Package Includes

✔ 1 × Dragino WSS-23 Air Quality Sensor (RS485)
👉 Ready for integration with RS485 weather station systems.

━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━

🛠 Related Product

Dragino WSC2-L LoRaWAN® Main Process Unit and RS485 Converter

━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━

📥 Product Downloads

📄 Datasheet
📖 User Manual

📌 Specifications

  • Measured Parameters: CO₂, PM2.5, PM10
  • Interface / Protocol: RS485 / Modbus RTU
  • Power Supply: DC 7–24V
  • Warm-up Time: ~3 minutes
  • Power Consumption: ~50 mA @ 12V

🧪 Measurement

  • CO₂ Range: 0 – 5000 ppm
  • CO₂ Accuracy: ±3% F.S (at 25°C)
  • CO₂ Resolution: 1 ppm
  • PM2.5 / PM10 Range: 0 – 1000 µg/m³
  • PM Accuracy: ±3% F.S (at 25°C)
  • PM Resolution: 1 µg/m³

🌡️ Operating Conditions

  • Operating Temperature: CO₂: 0 – 50°C · PM: -30 – 50°C
  • Operating Humidity: CO₂: 0 – 95% RH · PM: 15 – 80% RH (non-condensing)
